Yealink SIP-T41S Configuration Guide

BROADSOFT PARTNER CONFIGURATION GUIDE – YEALINK T4X IP PHONE 20-BD5476-00
©
2017 BROADSOFT INC. PAGE 32 OF 150
Figure 14 Account Register Page
3)
Browse to the Account → Advanced page and set the SIP Server Type to “Broadsoft”.
Figure 15 SIP Server Type Field
4)
To configure the Call Center features listed in the following table, see the related
autop parameters.
Step Command Purpose
Step 1 Enable ACD feature for the line.
Example:
account.1.acd.enable =1
Enable ACD feature.
 0 for Disabled
 1 for Enabled
Step 2 Set the phone to display the Unavailable and
Available soft keys after logging into the ACD
system for the line.
Example:
account.1.acd.available = 1
The Unavailable/Available soft
key appears on the LCD screen
when the phone logging to the
ACD system.
 0 for Disabled
 1 for Enabled
Step 3 Configure the initial agent state for the line.
Example
account.1.acd.initial_state = 1
Configure the initial agent state.
 1 for Available
 2 for Unavailable
Step 4 Configure the unavailable code for the line.
account.X.reason_code.Y = code
account.X.reason_code_name.Y = name
Example:
account.1.acd.unavailable_reason_ena
ble = 1
account.1.reason_code.1 = 100
account.1.reason_code_name.1= rest
Enable unavailable code
feature.
 0 for Disabled
 1 for Enable
The unavailable code length
must be within 10 characters.
The unavailable reason length
must be within 40 characters.
Value Y must be continuous,
with minimum and maximum as
1 and 100.

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
