BroadWorks Device Management Interoperability Test Plan Support Table
Test Plan Package Test Plan Package Items Supported Comments
No Touch Provision via Vendor
redirect
No* See section 5.2.5.3 No Touch
Provisioning via Yealink
Redirect Service.
5.2 Device Management Configuration
This section identifies the steps required to enable the Yealink T4x IP Phone for device
management. For Device Management configuration details not covered here, see the
BroadWorks Device Management Configuration Guide [2] and the BroadWorks CPE Kit
Usage Guide [8].
5.2.1 Configure BroadWorks Tags
The template files in Device Management use tags to represent the data stored on
BroadWorks. When a configuration changes for a user, Device Management parses the
template files and replaces the Device Management tags with the associated data stored
on BroadWorks. There are default tags defined in the Device Management software and
there are custom tags that the service provider can create/define via the web portal for use
by Device Management. There are two types of custom tags that can be defined:
system-default tags are common to all phones on the system; device type-specific tags
are common to Yealink T4x phone models only.
The Yealink T4x IP Phone makes use of dynamic tags, which may be configured by a
BroadWorks administrator as either system default or device type-specific tags. This
section identifies the required tags.
5.2.1.1 Create System Default Tags
Browse to System → Resources → Device Management Tag Sets and select the System
Default tag set. Add the system default tags in the following table if they do not already
exist.
Tag Name Valid Settings Description
%SNTP_SERVER_1% IP address/FQDN NTP server address
%SNTP_SERVER_2% IP address/FQDN NTP server address alternate
%DNS_SERVER_1% IP address DNS server address
%DNS_SERVER_2% IP address DNS server address alternate
%SBC_ADDRESS% IP address/FQDN SBC SIP address
%SBC_PORT% Port SBC SIP port
%USE_SBC_BOOLEAN% 0/1 Use SBC: 1=yes, 0=no
%XSP_ADDRESS_XSI_A
CTIONS%
IP address/FQDN Xtended Services Platform server
address

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
