Yealink SIP-T41S Configuration Guide

BROADSOFT PARTNER CONFIGURATION GUIDE – YEALINK T4X IP PHONE 20-BD5476-00
©
2017 BROADSOFT INC. PAGE 42 OF 150
Step Command Purpose
Step 8 Enable the enterprise common directory to be
displayed on the IP phone.
Example:
bw_phonebook.enterprise_common_enable
= 1
Enable the enterprise common
directory to be displayed on the
IP phone.
0 = Disabled
1 = Enabled
Step 9 Configure the enterprise common directory name
displayed on the IP phone.
Example:
bw_phonebook.enterprise_common_display
name = EnterpriseCommon
Configure “EnterpriseCommon”
as the enterprise common
directory name displayed on
the IP phone.
The default value is
“EnterpriseCommon”.
Step 10 Enable the personal directory to be displayed on
the IP phone.
Example:
bw_phonebook.personal_enable = 1
Enable the personal directory
to be displayed on the IP
phone.
0 = Disabled
1 = Enabled
Step 11 Configure the personal directory name displayed on
the IP phone.
bw_phonebook.personal_displayname =
Personal
Configure “Personal” as the
personal directory name
displayed on the IP phone.
The default value is “Personal”.
Step 12 Enable the custom directory feature.
Example:
bw_phonebook.custom = 1
Enable the custom directory
feature.
0 = Disabled
1 = Enabled
4.4.3 BroadWorks Call Logs Configuration
Integration with the BroadWorks Xtended Services Interface for Call Logs enables the
phone to get call log history (missed, placed, and received calls) from BroadWorks and
make them available to a user via the phone menus. To enable this feature, perform the
following step.
Step Command Purpose
Step 1 Enable the BroadSoft call log feature.
Example:
bw.xsi.call_log_enable = 1
Enable BroadWorks call log
feature.
 0 for Disabled
 1 for Enabled
Configure the phone as shown in the following figure.

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
