Yealink SIP-T41S Configuration Guide

BROADSOFT PARTNER CONFIGURATION GUIDE – YEALINK T4X IP PHONE 20-BD5476-00
©
2017 BROADSOFT INC. PAGE 40 OF 150
Figure 23 Xtended Services Platform Configuration
4.4.1 BroadWorks User Service Configuration
Integration with the BroadWorks Xtended Services Interface for User Service
Configuration enables the phone to display and configure BroadWorks user services, such
as Remote Office, BroadWorks Anywhere, Call Forwarding, and Simultaneous Ring. To
enable User Service Configuration, perform the following steps.
Step Command Purpose
Step 1 bw.xsi.enable =
Example:
bw.xsi.enable = 1
Enable XSI feature.
 0 for Disabled
 1 for Enable
Step 2 sip.authentication_for_xsi =
Example:
sip.authentication_for_xsi = 1
Enable the Xsp authentication
mode.
 0= BroadWorks User Login
credentials
 1= SIP Authentication
credentials
Step 3 account.1.xsi.user=
account.1.xsi.password =
Example:
account.1.xsi.user= 2405551111
account.1.xsi.password = 123456
Set the Xsi login user name
and password for line 1.
Step 4 account.1.xsi.host =
Example:
account.1.xsi.host =xsp1.iop1.broadworks.net
Set the IP address or domain
name of the Xsp server.

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
