Yealink SIP-T41S Configuration Guide

BROADSOFT PARTNER CONFIGURATION GUIDE – YEALINK T4X IP PHONE 20-BD5476-00
©
2017 BROADSOFT INC. PAGE 43 OF 150
Figure 24 Call Logs Configuration
4.4.4 BroadWorks Call Park Configuration
Integration with the BroadWorks Xtended Services Interface for Call Park makes call park
available to a user via the phone menus. To enable this feature, perform the following
steps.
Step Command Purpose
Step 1 Enable call park feature for the line.
Example:
account.1.callpark_enable= 1
Enable the Call Park feature.
0 = Disabled
1 = Enabled
Step 2 Enable the phone to display the Park soft key
during a call.
Example:
features.call_park.enable = 1
The Park soft key appears on
the LCD screen during a call.
0 = Disabled
1 = Enabled
Step 3 Enable the phone to display the GPark soft key
during a call.
Example:
features.call_park.group_enable= 1
The GPark soft key appears on
the LCD screen during a call.
0 = Disabled
1 = Enabled
Step 4 Enable the phone to play a warning tone when a
call is parked against its line.
Example:
features.call_park.park_ring = 1
Enable the phone to play a
warning tone when a call is
parked against its line.
0 = Disabled
1 = Enabled
Step 5 Enable the phone to display a parked indicator
when a call is parked against its line.
Example:
features.call_park.park_visual_notif
y_enable = 1
Enable the phone to display a
parked indicator when a call is
parked against its line.
0 = Disabled
1 = Enabled
Configure the Call Park settings as shown in the following figure.

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
