Unitary Products Group 13
TABLE 15: 15 TON CAPACITY TABLE - 85° AND 95°F
15 Ton Capacity Tables
HB180 Matched with LB180
AIR ON EVAPORATOR
OUTDOOR AMBIENT TEMPERATURE (F):
85°
CFM
W.B. GROSS INPUT
86
GROSS SENSIBLE CAPACITY (MBh)
TEMP CAP. POWER (RETURN AIR DRY BULB TEMP.- (F)
(F) (MBh) (kW) 83 80 77 74 71 68
4500
72 197.8 15.23 117.3 104.5 91.6 78.8 66.0 #N/A #N/A
67 183.8 14.90 144.8 131.9 119.1 106.3 93.4 80.6 67.8
62 170.5 14.50 168.2 155.4 142.6 129.8 116.9 104.1 91.3
57 173.8 14.43 173.8 171.0 158.2 145.3 132.5 119.7 106.9
5250
72 204.1 15.34 129.7 114.5 99.4 84.2 69.0 #N/A #N/A
67 189.6 15.01 159.4 144.3 129.1 114.0 98.8 83.6 68.5
62 175.9 14.60 174.8 168.3 154.6 139.4 124.3 109.1 93.9
57 179.3 14.53 179.3 177.9 171.5 156.3 141.2 126.0 110.8
6000
72 210.3 15.44 142.1 124.6 107.1 89.6 72.1 #N/A #N/A
67 195.4 15.12 174.1 156.6 139.1 121.6 104.1 86.6 69.2
62 181.3 14.70 181.3 181.3 166.6 149.1 131.6 114.1 96.6
57 184.8 14.64 184.8 184.8 184.8 167.3 149.8 132.3 114.8
6750
72 213.6 15.54 152.3 132.4 112.5 92.6 72.6 #N/A #N/A
67 198.4 15.21 186.0 166.1 146.2 126.3 106.3 86.4 66.5
62 184.0 14.80 184.0 184.0 175.0 155.1 135.2 115.3 95.3
57 187.6 14.73 187.6 187.6 187.6 167.7 147.8 127.8 107.9
7500
72 216.8 15.64 162.6 140.3 117.9 95.6 73.2 #N/A #N/A
67 201.4 15.31 198.0 175.6 153.3 130.9 108.5 86.2 63.8
62 186.8 14.89 186.8 186.8 183.5 161.1 138.8 116.4 94.1
57 190.5 14.82 190.5 190.5 190.5 168.1 145.7 123.4 101.0
Indicates Nominal Capacity Rating Point.
INPUT POWER INCLUDES THE CONDENSER AND COMPRESSOR MOTORS BUT NOT THE INDOOR BLOWER MOTOR
15 Ton Capacity Tables
HB180 Matched with LB180
AIR ON EVAPORATOR
OUTDOOR AMBIENT TEMPERATURE (F):
95°
CFM
W.B. GROSS INPUT
86
GROSS SENSIBLE CAPACITY (MBh)
TEMP CAP. POWER (RETURN AIR DRY BULB TEMP.- (F)
(F) (MBh) (kW) 83 80 77 74 71 68
4500
72 190.9 16.89 114.1 101.3 88.5 75.7 62.8 #N/A #N/A
67 176.8 16.51 142.2 129.4 116.5 103.7 90.9 78.0 65.2
62 162.8 16.18 162.8 153.2 140.3 127.5 114.7 101.8 89.0
57 163.2 16.11 163.2 158.1 145.2 132.4 119.6 106.7 93.9
5250
72 196.2 16.99 126.2 111.0 95.8 80.7 65.5 #N/A #N/A
67 181.7 16.61 156.5 141.4 126.2 111.0 95.9 80.7 65.6
62 167.4 16.27 167.4 162.5 152.0 136.8 121.6 106.5 91.3
57 167.7 16.20 167.7 165.2 157.3 142.1 127.0 111.8 96.6
6000
72 201.5 17.09 138.2 120.7 103.2 85.7 68.2 #N/A #N/A
67 186.6 16.71 170.9 153.4 135.9 118.4 100.9 83.4 65.9
62 171.9 16.37 171.9 171.9 163.6 146.1 128.6 111.1 93.6
57 172.3 16.30 172.3 172.3 169.3 151.8 134.4 116.9 99.4
6750
72 205.1 17.17 148.4 128.5 108.6 88.6 68.7 #N/A #N/A
67 190.0 16.79 182.1 162.9 143.0 123.1 103.1 83.2 63.3
62 175.0 16.45 175.0 175.0 170.9 150.9 131.0 111.1 91.2
57 175.4 16.37 175.4 175.4 173.9 154.0 134.1 114.2 94.2
7500
72 208.8 17.25 158.7 136.3 114.0 91.6 69.2 #N/A #N/A
67 193.4 16.86 193.4 172.4 150.1 127.7 105.4 83.0 60.7
62 178.1 16.52 178.1 178.1 178.1 155.7 133.4 111.0 88.7
57 178.5 16.45 178.5 178.5 178.5 156.2 133.8 111.4 89.1
Indicates Nominal Capacity Rating Point.
INPUT POWER INCLUDES THE CONDENSER AND COMPRESSOR MOTORS BUT NOT THE INDOOR BLOWER MOTOR
