TABLE 18: 20 TON CAPACITY TABLE - 85° AND 95°F
20 Ton Capacity Tables
HB240 & LB240
AIR ON EVAPORATOR
OUTDOOR AMBIENT TEMPERATURE (F):
85°
CFM
W.B. GROSS INPUT
86
GROSS SENSIBLE CAPACITY (MBh)
TEMP CAP. POWER (RETURN AIR DRY BULB TEMP.- (F)
(F) (MBh) (kW) 83 80 77 74 71 68
6000
72
263.4 21.25 155.9 138.8 121.7 104.6 87.5 #N/A #N/A
67
243.5 20.69 191.0 173.9 156.8 139.7 122.6 105.5 88.4
62
227.6 20.42 221.1 204.0 186.9 169.8 152.7 135.6 118.5
57
219.5 20.19 219.5 216.7 199.6 182.5 165.4 148.3 131.2
7000
72
273.9 21.38 172.8 152.6 132.4 112.2 91.9 #N/A #N/A
67
253.2 20.82 211.0 190.8 170.6 150.3 130.1 109.9 89.7
62
236.7 20.54 233.4 223.5 203.3 183.1 162.9 142.6 122.4
57
228.2 20.31 228.2 226.8 217.1 196.9 176.7 156.4 136.2
8000
72
284.4 21.51 189.7 166.4 143.0 119.7 96.4 #N/A #N/A
67
262.9 20.94 231.0 207.6 184.3 161.0 137.6 114.3 91.0
62
245.7 20.67 245.7 243.0 219.7 196.3 173.0 149.7 126.4
57
237.0 20.43 237.0 237.0 234.6 211.3 187.9 164.6 141.3
8600
72
289.0 21.64 197.6 172.2 146.8 121.5 96.1 #N/A #N/A
67
267.2 21.06 239.9 214.6 189.2 163.8 138.4 113.0 87.7
62
249.7 20.79 249.7 248.3 225.5 200.1 174.7 149.4 124.0
57
240.8 20.55 240.8 240.8 239.6 214.2 188.9 163.5 138.1
9200
72
293.6 21.76 205.5 178.0 150.6 123.2 95.8 #N/A #N/A
67
271.4 21.19 248.9 221.5 194.1 166.6 139.2 111.8 84.4
62
253.7 20.91 253.7 253.7 231.3 203.9 176.5 149.0 121.6
57
244.6 20.67 244.6 244.6 244.6 217.2 189.8 162.4 134.9
Indicates Nominal Capacity Rating Point.
INPUT POWER INCLUDES THE CONDENSER AND COMPRESSOR MOTORS BUT NOT THE INDOOR BLOWER MOTOR
20 Ton Capacity Tables
HB240 & LB240
AIR ON EVAPORATOR
OUTDOOR AMBIENT TEMPERATURE (F):
95°
CFM
W.B. GROSS INPUT GROSS SENSIBLE CAPACITY (MBh)
TEMP CAP. POWER (RETURN AIR DRY BULB TEMP.- (F)
(F) (MBh) (kW) 86 83 80 77 74 71 68
6000
72
253.7 23.11 151.3 134.2 117.0 99.9 82.8 #N/A #N/A
67
237.2 22.68 188.2 171.1 153.9 136.8 119.7 102.6 85.5
62
218.5 22.16 218.5 202.7 185.6 168.5 151.4 134.3 117.2
57
214.5 22.11 214.5 210.5 193.4 176.3 159.1 142.0 124.9
7000
72
262.8 23.30 167.5 147.3 127.1 106.8 86.6 #N/A #N/A
67
245.7 22.88 207.5 187.3 167.1 146.9 126.7 106.5 86.2
62
226.4 22.35 226.4 218.5 201.5 181.3 161.0 140.8 120.6
57
222.2 22.30 222.2 220.2 209.9 189.7 169.5 149.2 129.0
8000
72
271.9 23.50 183.7 160.4 137.1 113.7 90.4 #N/A #N/A
67
254.3 23.07 226.9 203.6 180.3 156.9 133.6 110.3 87.0
62
234.2 22.54 234.2 234.2 217.3 194.0 170.7 147.4 124.0
57
229.9 22.49 229.9 229.9 226.4 203.1 179.8 156.4 133.1
8600
72
269.7 23.60 189.5 164.1 138.7 113.3 88.0 #N/A #N/A
67
252.2 23.16 233.2 207.8 182.4 157.1 131.7 106.3 80.9
62
232.3 22.63 232.3 232.3 220.0 194.6 169.2 143.8 118.5
57
228.0 22.58 228.0 228.0 226.3 200.9 175.5 150.2 124.8
9200
72
267.6 23.69 195.2 167.8 140.4 112.9 85.5 #N/A #N/A
67
250.2 23.26 239.5 212.0 184.6 157.2 129.8 102.3 74.9
62
230.4 22.72 230.4 230.4 222.6 195.2 167.7 140.3 112.9
57
226.2 22.68 226.2 226.2 226.2 198.7 171.3 143.9 116.5
Indicates Nominal Capacity Rating Point.
INPUT POWER INCLUDES THE CONDENSER AND COMPRESSOR MOTORS BUT NOT THE INDOOR BLOWER MOTOR
