York HB 180 User Manual

036-21323-002-C-0206
20 Unitary Products Group
TABLE 23: BLOWER DRIVE DATA
Unit Model
Drive Data
Model Number Blower RPM Range
Adj. Motor Pulley Fixed Blower pulley Belts
Datum Dia. (In.) Bore (In.) Datum Dia. (In.) Bore (In.) Qty. Designation
LB180
1LD0436 640-810 4.0-5.0 7/8 11 1-3/16 1 A57
1LD0437 800-1000 5.3-6.3 1-1/8 11 1-3/16 2 A55
LB240
1LD0438 580-720 4.0-5.0 1-1/8 12 1-3/16 2 A63
1LD0439 700-830 4.0-5.0 1-1/8 13 1-3/16 2 A68
TABLE 24: BLOWER DATA
Unit
Model
Blower Motor Data
1
Drive Data
HP Model Number Frame size Voltage (3PH-60Hz.)
Model
Number
Blower RPM
Range
LB180
3
2LR04603033 56
208/230/460
1
1LD0436 640-810
2LR04603058 56 575 1LD0436 640-810
5
2LR04605023 184 208 1LD0437 800-1000
2LR04605032 184 230/460 1LD0437 800-1000
2LP04605058 184 575
1LD0437 800-1000
1LD0439 700-830
LB240 5
2LR04605023 184 208
1LD0438 580-720
1LD0439 700-830
2LR04605032 184 208/230/460
1LD0438 580-720
1LD0439 700-830
2LP04605058 184 575
1LD0437 800-1000
1LD0439 700-830
1. Three-phase motors will always be wired for 460 volt power supply. Refer to the wiring diagram inside the motor terminal box.
TABLE 25: INDOOR ELECTRICAL RATINGS
Model
Number
Blower Motor HP Power Supply FLA
Minimum Circuit
Ampacity
Max. Fuse Size
1
LB180
3
208-3-60 10.6 13.3 20
230-3-60 9.6 12.0 20
5
208-3-60 17.5 21.9 35
230-3-60 16.7 20.9 35
3
460-3-60 4.8 6.0 15
575-3-60 3.6 4.5 15
5
460-3-60 7.6 9.5 15
575-3-60 5.2 6.5 15
LB240 5
208-3-60 17.5 21.9 35
230-3-60 16.7 20.9 35
460-3-60 7.6 9.5 15
575-3-60 5.2 6.5 15
1. Maximum fuse or maximum circuit breaker (HACR type per NEC).
