Unitary Products Group 15
TABLE 17: 15 TON CAPACITY TABLE - 125°F
15 Ton Capacity Tables
HB180 Matched with LB180
AIR ON EVAPORATOR
OUTDOOR AMBIENT TEMPERATURE (F):
125°
CFM
W.B. GROSS INPUT
86
GROSS SENSIBLE CAPACITY (MBh)
TEMP CAP. POWER (RETURN AIR DRY BULB TEMP.- (F)
(F) (MBh) (kW) 83 80 77 74 71 68
4500
72
166.6 22.9 107.4 94.6 81.8 68.9 56.1 #N/A #N/A
67
153.1 22.2 133.1 120.3 107.4 94.6 81.8 68.9 56.1
62
142.7 21.6 142.7 142.7 132.0 119.2 106.4 93.5 80.7
57
147.1 21.8 147.1 141.3 128.5 115.7 102.8 90.0 77.2
5250
72
170.4 23.1 118.5 103.4 88.2 73.1 57.9 #N/A #N/A
67
156.6 22.5 146.2 131.1 115.9 100.8 85.6 70.4 55.3
62
146.0 21.8 146.0 146.0 142.5 127.3 112.1 97.0 81.8
57
150.4 22.0 150.4 147.6 138.6 123.5 108.3 93.1 78.0
6000
72
174.2 23.3 129.7 112.2 94.7 77.2 59.7 #N/A #N/A
67
160.1 22.7 159.4 141.9 124.4 106.9 89.4 71.9 54.4
62
149.2 22.1 149.2 149.2 149.2 135.4 117.9 100.4 82.9
57
153.8 22.2 153.8 153.8 148.8 131.3 113.8 96.3 78.8
6750
72
178.0 23.4 141.5 121.5 101.6 81.7 61.8 #N/A #N/A
67
163.6 22.7 163.3 153.5 133.5 113.6 93.7 73.8 53.8
62
152.5 22.1 152.5 152.5 152.5 134.4 114.5 94.6 74.7
57
157.2 22.2 157.2 157.2 154.7 134.7 114.8 94.9 75.0
7500
72
181.9 23.4 153.3 130.9 108.6 86.2 63.9 #N/A #N/A
67
167.2 22.7 167.2 165.0 142.7 120.3 98.0 75.6 53.2
62
155.8 22.1 155.8 155.8 155.8 133.5 111.1 88.8 66.4
57
160.6 22.3 160.6 160.6 160.6 138.2 115.9 93.5 71.2
Indicates Nominal Capacity Rating Point.
INPUT POWER INCLUDES THE CONDENSER AND COMPRESSOR MOTORS BUT NOT THE INDOOR BLOWER MOTOR
