SECTION 4 - PRINTERS
FIGURE 35 - SAMPLE PRINTOUT (STATUS)
YORK UPDATE
CHILLER ID 0
(c) 1997 – 2001 YORK INTERNATIONAL CORPORATION
Mon 21 Jun 1999 1:26:51 PM
SYSTEM RUN
LEAVING CHILLED LIQUID CONTROL
[List all warnings presently active]
Controls C.MLM.05.02.102
Run Time 0 Days 2 Hr 59 Min
Operating Hours = 298 Hr
Number Of Starts = 106
Control Source = Local
Evaporator
–––––––––––––––––––––––––––––––––––––––––––––––––––––
Leaving Chilled Active Setpoint = 45.0°F
Chilled Liquid Pump = Run
Chilled Liquid Flow Switch = Closed
Leaving Chilled Liquid Temperature = 50.0°F
Return Chilled Liquid Temperature = 59.3°F
Evaporator Pressure = 78.2 Psig
Evaporator Saturation Temperature = 41.1°F
Small Temperature Di󰀨erence = 10.0 ~F
Condenser
–––––––––––––––––––––––––––––––––––––––––––––––––––––
Condenser Liquid Pump = Run
Condenser Liquid Flow Switch = Closed
Leaving Condenser Liquid Temperature = 85.0°F
Return Condenser Liquid Temperature = 94.9°F
Condenser Pressure = 135.8 Psig
Condenser Saturation Temperature = 71.7°F
Small Temperature Di󰀨erence = -13.3°F
Drop Leg Refrigerant Temperature = 85.0°F
[If Drop Leg Sensor enabled]
Sub Cooling Temperature = 2.0°F
[If Drop Leg Sensor enabled]
Compressor
–––––––––––––––––––––––––––––––––––––––––––––––––––––
Discharge Temperature = 121.6°F
Discharge Pressure = 135.7 Psig
Discharge Saturation Temperature = 120.6ºF
Discharge Superheat = 1.0°F
Liquid Injector = Open
Low Superheat Event = 6
Low Superheat Run Time = 8 min
[Skip the following section if Hot Gas Bypass is not enabled] Hot Gas
––––––––––––––––––––––––––––––––––––––––––––––––––––––
Hot Gas Solenoid On = False
Oil Sump
––––––––––––––––––––––––––––––––––––––––––––––––––––––
Oil Pressure = 120.7 Psig
Di󰀨erential Oil Pressure = 41.6 Psid
Di󰀨erential Filter Pressure = 13.1 Psid
Oil Supply Solenoid = On
[Skip the following section if Level Control is not enabled] Refrigerant
Level Control
––––––––––––––––––––––––––––––––––––––––––––––––––––––
Refrigerant Level Target = 80 %
Refrigerant Level Position = 35 %
Ramp Up Time Remaining = 15 Sec
[If Ramp Up in e󰀨ect]
[Skip the following section if Motor Type is not EM]
Electro-Mechanical Starter
–––––––––––––––––––––––––––––––––––––––––––––––––––––––
Motor Run = On % Full Load Amps = 94 %
[Skip the following section if Motor Type is not Mod A SSS] Liquid-
Cooled Solid State Starter
––––––––––––––––––––––––––––––––––––––––––––––––––––––
Motor Run = On
% Full Load Amps = 94
% Phase A Voltage = 447 V
Phase B Voltage = 409 V
Phase C Voltage = 442 V
Phase A Current = 193 A
Phase B Current = 204 A
Phase C Current = 190 A
[Skip the following section if Motor Type is not Mod B SSS]
Liquid-Cooled Solid State Starter
––––––––––––––––––––––––––––––––––––––––––––––––––––––
Motor Run = On
% Full Load Amps = 94
% Starter Model = 33L
KW Hours = 20723 KWH
Input Power = 145 KW
Phase A Voltage = 447 V
Phase B Voltage = 409 V
Phase C Voltage = 442 V
Phase A Current = 193 A
Phase B Current = 204 A
Phase C Current = 190 A
Phase A Temperature = 88 ~F
Phase B Temperature = 89 ~F
Phase C Temperature = 75 ~F
