SECTION 4 - PRINTERS
FIGURE 38 - SAMPLE PRINTOUT (SALES ORDER)
NAMEPLATE INFORMATION
––––––––––––––––––––––––––––––––––––––––––––––––––––
MOTOR CODE CV
POWER (VOLTS) 460
PHASES 3
FREQUENCY (HZ) 60
LOCKED ROTOR AMPS 4400
FULL LOAD AMPS 642
INRUSH AMPS 655
SYSTEM INFORMATION
––––––––––––––––––––––––––––––––––––––––––––––––––––
REFRIGERANT R134A
TONS 150
GEAR CODE RK
LIQUID TYPE WATER
BRINE PERCENT
KILOWATTS INPUT 467
VSD / SSS / EM SSS
YORK SALES ORDER
CHILLER ID 3
© 1997 - 1999 YORK INTERNATIONAL CORPORATION
MON 29 MAR 1999 1 28 PM
ORDER INFORMATION
––––––––––––––––––––––––––––––––––––––––––––––––––––
COMMISSIONING DATE 01 OCT 1999
JOB NAME
JOB LOCATION
MODEL NUMBER YSFBFAS3-CVE
YORK ORDER NUMBER 99102014-01
PANEL SERIAL NUMBER 12345678
CHILLER SERIAL NUMBER 12345678
DESIGN LOAD - EVAPORATOR
––––––––––––––––––––––––––––––––––––––––––––––––––––
PASSES 2
DESIGN WORKING PRESSURE 150
FOULING FACTOR 0.00010
PRESSURE DROP 21.1
NOZZLE ARRANGEMENT IN 2
NOZZLE ARRANGEMENT OUT 3
LEAVING TEMPERATURE 44.0
RETURN TEMPERATURE 56.0
GPM 1500.0
TUBES 181
DESIGN LOAD - CONDENSER
––––––––––––––––––––––––––––––––––––––––––––––––––––
PASSES 2
DESIGN WORKING PRESSURE 150
FOULING FACTOR 0.00025
PRESSURE DROP 28.0
NOZZLE ARRANGEMENT IN 1
NOZZLE ARRANGEMENT OUT
LEAVING TEMPERATURE 94.3
RETURN TEMPERATURE 85.0
GPM 2250.0
TUBES 230
