SECTION 4 - PRINTERS
4
FIGURE 36 - SAMPLE PRINTOUT (SETPOINT REPORT)
YORK SETPOINTS
CHILLER ID 0
(c) 1997 – 2001 YORK INTERNATIONAL CORPORATION
Mon 21 Jun 1999 1:27:39 PM
Software Versions
–––––––––––––––––––––––––––––––––––––––––––––––––––––
Controls = C.MLM.05.02.102
BIOS = C.MLM.00.03
Kernel = 0.18 GUI = 0.32
SIO = 0.22
GPIC = 0.05
SSS [Skip if Motor Type is not Serial SSS] = C.SSS.01.01
System Information
–––––––––––––––––––––––––––––––––––––––––––––––––––––
System Language = English
Data Display Mode = English
Control Source = Local
Remote Analog Input Range = 0 – 10 Volts
Clock = Enabled
Flow Switch = Analog
Jumper Settings
–––––––––––––––––––––––––––––––––––––––––––––––––––––
Chilled Liquid Pump Operation = Standard
Anti-Recycle = Enabled
Power Failure Restart = Auto
Liquid Type = Water
Motor Type = EM
Printer Setup
–––––––––––––––––––––––––––––––––––––––––––––––––––––
Automatic Printer Logging = Disabled
Log Start Time = 12:00 am
Output Interval = 60 Min
Printer Type = Okidata
Baud = 9600 Baud
Data Bits = 8 Bits
Parity = None
Stop Bits = 1 Bit
COM 2 Setup
–––––––––––––––––––––––––––––––––––––––––––––––––––––
Baud = 19200 Baud
Data Bits = 8 Bits
Parity = Odd
Stop Bits = 1 Bit
Evaporator
–––––––––––––––––––––––––––––––––––––––––––––––––––––
Leaving Chilled Local Setpoint = 45.0 ~F
Leaving Chilled ISN Setpoint = 45.0 ~F
Leaving Chilled Modem Setpoint = 45.0 ~F
Leaving Chilled Analog Setpoint = 45.0 ~F
Leaving Chilled Digital Setpoint = 45.0 ~F
Period = 10 Sec
Error = 1.5 ~F
Rate = 2.5 ~F/S
Max Load Pulse = 1.5 Sec
Max Unload Pulse = 1.5 Sec
Remote Range = 10.0 ~F
Restart O󰀨set = 0.0 ~F
Restart Setpoint = 45.0 ~F
Shutdown O󰀨set = 4.0 ~F
Shutdown Setpoint = 41.0 ~F
Brine Low Evaporator Cutout = 25.0 Psig
Ice Storage = O󰀨
O󰀨set = 0
Condenser
––––––––––––––––––––––––––––––––––––––––––––––––––––––
High Pressure Warning Threshold = 44.9 Psig
Drop Leg = Enabled Freeze
Warning = Disabled
Freeze Time = 30 Min
[Skip the following section if Hot Gas Bypass is not enabled]
Hot Gas
––––––––––––––––––––––––––––––––––––––––––––––––––––––
Hot Gas = Disabled O󰀨
Setpoint = 2.0 ~F
On Setpoint = 1.0 ~F
Oil Sump
––––––––––––––––––––––––––––––––––––––––––––––––––––––
Auto Zero = Enable
Compressor
––––––––––––––––––––––––––––––––––––––––––––––––––––––
Maximum Load Temperature = 70.0 ~F
Maximum Load FLA = 60 %
Motor FLA Limit = 15 %
Liquid Injection Threshold = 130.0 ~F
[Skip the following section if Liquid Level is not enabled] Refrigerant
Level Control
––––––––––––––––––––––––––––––––––––––––––––––––––––––
Level Control = Enabled
Setpoint = 50 %
Valve Preset Time = 45 Sec
[Skip the following section if Motor Type is not EM]
Electro-Mechanical Starter
––––––––––––––––––––––––––––––––––––––––––––––––––––––
Local Motor Current Limit = 100 %
Remote ISN Current Limit = 100 %
Remote Analog Current Limit = 100 %
Remote Digital Current Limit = 100 %
Remote Modem Current Limit = 100 %
Pulldown Demand Limit = 100 %
Pulldown Demand Time = 0 Min
[Skip the following section if Motor Type is not Mod A SSS] Liquid-
Cooled Solid State Starter
––––––––––––––––––––––––––––––––––––––––––––––––––––––
Local Motor Current Limit = 100 %
Remote ISN Current Limit = 100 %
Remote Analog Current Limit = 100 %
