SECTION 4 - PRINTERS
4
The Control Center provides the required formatting
control codes for the printers above when the printer
is selected on the PRINTER screen in the instructions
below. These codes are transmitted through the serial
interface to the printer to provide a proper print format.
Different printers require different formatting control
codes. Other printers might provide proper operation
when connected to the Control Center. However, the
print format may not be correct or as desired. Proceed
with caution and use the following guidelines if an un-
listed printer is selected:
1. All must be capable of RS-232 Serial communica-
tions.
2. Primary dierences between printers involve the
formatting control codes required by the printer.
These codes are sent from the Control Center to
the printer. For example, Weigh -Tronix printers
require a control code to select 40 column width.
This same code is interpreted by the Okidata
printer as an instruction to print wide characters.
In some instances, a printer will ignore a code it
cannot interpret.
3. The Control Center requires a busy signal from
the printer when the printer receive buer is full.
This causes the Control Center to momentarily
terminate data transmission until the printer can
accept more data. The busy signal polarity must
be asserted low when busy.
PRINTER CONNECTIONS
Connect the printers to the Control Center Microboard
as follows. Only one printer can be connected at a
time.
Okidata 182, 182 turbo, 184 turbo
MICROBOARD PRINTER FUNCTION
J2-4 Pin 3 Tx (data to printer)
J2-2 Pin 11
DSR
(busy signal from printer)
J2-9 Pin 7 Gnd
Cabinet Shield
Weigh-Tronix
MICROBOARD PRINTER FUNCTION
J2-4 Pin 2 Tx (data to printer)
J2-2 Pin 5
DSR
(busy signal from printer)
J2-9 Pin 7 Gnd
Cabinet Shield
Seiko
MICROBOARD PRINTER FUNCTION
J2-4 Pin 3 Tx (data to printer)
J2-2 Pin 8
DSR
(busy signal from printer)
J2-9 Pin 5 Gnd
Cabinet Shield
Hardware
The hardwire required to connect the printer is as follows:
• Cable – #18 AWG stranded 50ft. maximum
length.
• Connectors –
- Microboard: None. Strip 1/4" insulation from
wire and insert into screw terminal block.
- Printers: Okidata - 25 pin plug DB-25P or
equivalent; Shell DB-C2-J9 or equivalent.
Weigh-Tronix - Same as Okidata. Cable as-
sembly available from Weigh-Tronix. Seiko -
9-Pin D-type Subminiature (DB-9 pin male).
PRINTER SETUP
The selected printer must be configured as follows. Re-
fer to manual provided by Printer manufacturer with
respective Printer.
Okidata 182, 182 Turbo, 184 Turbo Printer
CONTROL BOARD SWITCH SETTINGS
SW1 ON Unslashed 0
SW2 OFF Unslashed 0
SW3 OFF Unslashed 0
SW4 OFF Form Length 11 In.
SW5 ON Form Length 11 In.
SW6 OFF Auto Line Feed OFF
SW7 ON 8 Bit Data
SW8 OFF Enable Front Panel
If equipped with a SUPER SPEED serial board:
CONTROL BOARD SWITCH SETTINGS
SW1-1 ON Odd Or Even Parity
SW1-2 ON No Parity
SW1-3 ON 8 Bit Data
SW1-4 ON Protocol Ready/Busy
SW1-5 ON Test Select
SW1-6 ON Print Mode
SW1-7 OFF SDD (-) Pin 11
