Zebra 105SL User Guide Addendum

19
Introduction
External SEH IPv6 PS (PS105-Z) Technical Specifications
09/03/2008 Addendum to the SEH PS105-Z & PS102-Z User Guide P1004197-001
for Zebra Printers
External SEH IPv6 PS (PS105-Z)
Technical Specifications
General Specifications
Network Connection Ethernet 10BaseT and 100BaseT UTP RJ-45
connection Half and Full Duplex Communications
Printer Connection Bi-directional, IEEE-1284 Centronics parallel port
(Compatibility, Nibble, and ECP)
User Interface LED activity indicators:
• Status
• Link
• Network activity
Height (external dimensions) 1.0 in. 26 mm
Width (external dimensions) 2.5 in. 63 mm
Length (external dimensions) 3.9 in. 98 mm
Weight 2.8 oz. 70 g
Electrical Maximum 320mA at 5VDC Power provided by the
printer (Centronics pin 18, 5VDC at 320mA)
Temperature Operating 41° to 104°F 5° to 40°C
Storage –40° to 140°F –40° to 60°C
Relative Humidity Operating 5% to 80%, non-condensing
Storage 5% to 90%, non-condensing
Agency Approvals Agency Approvals
• CE: EN 55022, Class B
• EN 55024
Agency Marks
• CE
• FCC Class A
• VCCI Class B
• C-Tick
• WEEE (B-to-C)
• RoHS

Zebra 105SL Specifications

General

Print technology	Direct thermal
Display	LCD
Product color	Gray
Network ready	Yes
Dimensions (WxDxH)	283 x 495 x 394 mm
Standard interfaces	Parallel, Serial
Internal memory	6 MB
Maximum label width	115 mm
Maximum label length	0.991 m
Power requirements	90-264 VAC, 48-63 Hz

Weight and Dimensions

Depth	495 mm
Width	283 mm
Height	394 mm
Weight	29000 g
