P1004197-001 Addendum to the SEH PS105-Z & PS102-Z User Guide 09/03/2008
for Zebra Printers
Parameters for V53.16.x, R53.16.x, or later Firmware
The following printers use firmware versions V53.16.x, R53.16.x, or later:
• ZM400, ZM600
•RZ400, RZ600
Firmware Requirements Table 4 shows the wireless parameters that may be viewed or
modified through the printer’s control panel.
Network Password Some of the parameters can be password-protected by a network
password. By default, the network print servers run in an “unprotected” mode (password set to
0000), which means that you do not need to enter a network password through the control
panel to view or modify network settings. To set a network password (not the same as the
general printer password), use the
^WP ZPL command. For more specific details about ZPL
commands, see ZPL II
®
Programming Guide For x.14 Firmware and Above.
Table 4 • Wireless Parameters for V53.16.x and R53.16.x Firmware
(ZM400, ZM600, RZ400, and RZ600 Printers)
Parameter
Function
PRIMARY NETWORK
Select the Primary Network Device
This parameter tells if the printer uses IP settings from the wireless or a
wired print server at bootup.
Selections: WIRED, WIRELESS
Default Value: WIRED
LOAD FROM EXT?
2
View if IP Settings Are Loaded from the Printer or Print Server
This parameter tells if the printer should use IP settings from the external
print server at bootup.
Selections: YES, NO
Default Value: NO
ACTIVE PRINTSRVR
1
View the Active Print Server
This menu item displays which print server is being used. This tells which
device’s settings such as IP protocol and IP address are being displayed
under those menu items.
Selections:
• WIRELESS indicates that the wireless device is active.
• INTERNAL WIRED indicates that the internal 10/100 option board is
active.
• EXTERNAL WIRED indicates that the external print server is active.
• NONE indicates that at least one of the network options is installed but
none of them are active. When NONE is shown for this menu item, the
device-specific items such as IP protocol and IP address will not display.
Default Value: NONE

Zebra 105SL Specifications

General

Print technology	Direct thermal
Display	LCD
Product color	Gray
Network ready	Yes
Dimensions (WxDxH)	283 x 495 x 394 mm
Standard interfaces	Parallel, Serial
Internal memory	6 MB
Maximum label width	115 mm
Maximum label length	0.991 m
Power requirements	90-264 VAC, 48-63 Hz

Weight and Dimensions

Depth	495 mm
Width	283 mm
Height	394 mm
Weight	29000 g
