Zebra 105SL User Guide Addendum

Introduction
Internal SEH IPv6 PS (PS102-Z) Technical Specifications
20
P1004197-001 Addendum to the SEH PS105-Z & PS102-Z User Guide 09/03/2008
for Zebra Printers
Internal SEH IPv6 PS (PS102-Z)
Technical Specifications
General Specifications
Network Connection Ethernet 10BaseT and 100BaseT UTP RJ-45
connection Half and Full Duplex Communications
Printer Connection Bi-directional, IEEE-1284 Centronics parallel port
(Compatibility, Nibble, and ECP)
User Interface LED activity indicators:
• Status
• Link
• Network activity
Height (external dimensions) 0.7 in. 18 mm
Width (external dimensions) 3.3 in. 83 mm
Length (external dimensions) 3.7 in. 94 mm
Weight 1.4 oz. 40 g
Electrical Maximum 380mA at 5VDC Power provided by the
printer (Centronics pin 18, 5VDC at 380mA)
Temperature Operating 32° to 104°F 0° to 40°C
Storage –40° to 140°F –40° to 60°C
Relative Humidity Operating 5% to 80%, non-condensing
Storage 5% to 85%, non-condensing

Zebra 105SL Specifications

General

Print technology	Direct thermal
Display	LCD
Product color	Gray
Network ready	Yes
Dimensions (WxDxH)	283 x 495 x 394 mm
Standard interfaces	Parallel, Serial
Internal memory	6 MB
Maximum label width	115 mm
Maximum label length	0.991 m
Power requirements	90-264 VAC, 48-63 Hz

Weight and Dimensions

Depth	495 mm
Width	283 mm
Height	394 mm
Weight	29000 g
