Zebra 110Xi4 User Manual

Specifications
Features
156
P1009874-001 Xi4 User Guide 3/12/09
Features
This section lists the standard and optional features for the printer.
Standard Features
• Thermal transfer and direct thermal printing
• 16 MB SDRAM (12 MB user-available)
•USB 2.0 Port
•Real-time Clock
• Advanced Counter
• RS-232 serial port
• bidirectional parallel port
•USB 2.0
• XML-enabled printing
Optional Features
• ZebraNet Internal Wireless Plus Print Server
• ZebraNet 10/100 Print Server (internal or external)
• ZebraNet PrintServer II (internal or external)
• IBM twinax/coax interfaces (internal)
• Full-width rotary knife cutter and catch tray
• Media rewind spindle
• Factory-installed 64 MB (61 MB user available) Flash memory option
• Additional fonts
Print Modes
Five different print modes can be used, depending on the printer options purchased:
• Tear-Off Mode: Labels are produced in strips.
• Peel-Off Mode: Labels are dispensed and peeled from the backing as needed.
• Cutter Mode: Labels are printed and individually cut.
• Applicator Mode: The printer is part of a larger label application system.
• Rewind Mode: Labels are rewound internally.
Note • Printer specifications are subject to change without notice.

Zebra 110Xi4 Specifications

General

Maximum resolution	203 x 203 DPI
Core diameter	76 mm
Ribbon length	300 m
Media thickness	0.076 - 0.305 mm
Maximum media length	3810 mm
Maximum roll diameter	203 mm
Supported paper width	102 mm
Media thickness (imperial)	0.003 - 0.012 \
Maximum media length (imperial)	150 \
Supported paper width (imperial)	4 \
RS-232 ports	1
Standard interfaces	USB 2.0
Connectivity technology	Wired
Weight (imperial)	50 lbs
Dimensions (WxDxH)	261.9 x 517.5 x 393.7 mm
Flash memory	8 MB
Certification	-BSMI, -cTUVus, -CCC, -CE, -C-Tick, -EN55022 Class B, -EN55024, -EN61000-3-2, 3, -FCC Class B, -GOST-R, -ICES-003 Class B, -IEC 60950-1 / EN60950, -KCC, -NOM, -S Mark, -STB, -UkrSEPRO, -VCCI, -ZIK.
Internal memory	16 MB
Built-in barcodes	Code 39, Code 49, Code 93, MaxiCode, PDF417, Postnet, QR Code, UPC-A, UPC-E
Page description languages	XML, ZPL, ZPL II
Storage temperature (T-T)	-40 - 140 °F
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Power requirements	90 - 264 VAC, 48 - 62 Hz

Weight and Dimensions

Weight	22700 g
