Specifications
Media Specifications
3/12/09 Xi4 User Guide P1009874-001
110Xi4 Black Mark Sensing Only
140Xi4, 170Xi4, and 220Xi4 Printers
Media Specifications 110Xi4 200 dpi 110Xi4 300 dpi 110Xi4 600 dpi
Mark length (measuring parallel
to label/tag edge)
Minimum 0.12 in. (3 mm) 0.12 in. (3 mm) 0.12 in. (3 mm)
Maximum 0.43 in. (11 mm) 0.43 in. (11 mm) 0.43 in. (11 mm)
Mark width (measuring to
perpendicular
label/tag edge)
Minimum 0.43 in. (11 mm) 0.43 in. (11 mm) 0.43 in. (11 mm)
Maximum Full media width Full media width Full media width
Mark location within 0.040 in. (1 mm) of
the inside media edge
within 0.040 in. (1 mm) of
the inside media edge
within 0.040 in. (1 mm) of
the inside media edge
Mark density in Optical Density Unit (ODU) >1.0 >1.0 >1.0
Media Specifications 140Xi4 170Xi4 220Xi4
Minimum label length Tear-Off 0.7 in. (18 mm) 0.7 in. (18 mm) 0.7 in. (18 mm)
Peel-Off 0.5 in. (13 mm) 0.5 in. (13 mm) 0.5 in. (13 mm)
Cutter 1.5in. (38mm) 1.5in. (38mm) 1.5in. (38mm)
Rewind 0.25 in. (6 mm) 0.25 in. (6 mm) 0.25 in. (6 mm)
Total media width
(label + backing,
if any)
Minimum 1.57 in. (40 mm) 2.00 in. (51 mm) 4.25 in. (108 mm)
Maximum 5.51 in. (140 mm) 7.1 in. (180 mm) 8.80 in. (224 mm)
Total thickness
(includes backing, if any)
Minimum 0.003 in. (0.076 mm) 0.003 in. (0.076 mm) 0.003 in. (0.076 mm)
Maximum 0.012 in. (0.305 mm) 0.012 in. (0.305 mm) 0.012 in. (0.305 mm)
Cutter maximum full-width media thickness 0.009 in. (0.23 mm) 0.007 in. (0.18 mm) 0.005 in. (0.14 mm)
Roll media core inside diameter 3 in. (76 mm) 3 in. (76 mm) 3 in. (76 mm)
Maximum roll diameter on 3 in. (76 mm) core 8.0 in. (203 mm) 8.0 in. (203 mm) 8.0 in. (203 mm)
Interlabel gap Minimum 0.079 in. (2 mm) 0.079 in. (2 mm) 0.079 in. (2 mm)
Preferred 0.118 in. (3 mm) 0.118 in. (3 mm) 0.118 in. (3 mm)
Maximum No more than the calibrated
length of the label.
No more than the calibrated
length of the label.*
No more than the calibrated
length of the label.
Maximum internal fanfold media pack size (label
+ backing): L×W×H
8.0×5.5×4.5 in.
(203×140×114 mm)
8.0×7.1×4.5 in.
(203×180×114 mm)
8.0×8.8×4.5 in.
(203×224×114 mm)
Ticket/tag sensing notch: L×W 0.12×0.25 in. (3×6 mm) 0.12×0.25 in. (3×6 mm) 0.12×0.25 in. (3×6 mm)
Ticket/tag sensing hole diameter 0.125 in. (3 mm) 0.125 in. (3 mm) 0.125 in. (3 mm)
Effective leading edge registration accuracy
(vertical)
± 0.070 in. (± 1.8 mm) ± 0.070 in. (± 1.8 mm) ± 0.060 in. (± 1.5 mm)
Effective leading edge registration accuracy
(horizontal)
± 0.070 in. (± 1.8 mm) ± 0.070 in. (± 1.8 mm) ± 0.060 in. (± 1.5 mm)
