Zebra 110Xi4 User Manual

Specifications
General Specifications
158
P1009874-001 Xi4 User Guide 3/12/09
General Specifications
Physical Specifications
Electrical Specifications
Environmental Conditions for Operation and Storage
Dimensions 110Xi4 140Xi4 170Xi4 220Xi4
Height 15.5 in (393.7 mm) 15.5 in. (393.7 mm) 15.5 in. (393.7 mm) 15.5 in (393.7 mm)
Width 10.31 in. (261.9 mm) 11.31 in. (287.3 mm) 13.31 in. (338.1 mm) 15.81 in. (401.6 mm)
Depth 20.38 in. (517.5 mm) 20.38 in. (517.5 mm) 20.38 in. (517.5 mm) 20.38 in. (517.5 mm)
Weight without
options
50 lb. (22.7 kg) 55 lb. (25 kg) 67 lb. (30.5 kg) 72 lb. (32.7 kg)
Power 110Xi4 140Xi4 170Xi4 220Xi4
General 90 to 264 VAC;
48 to 62 Hz
90 to 264 VAC;
48 to 62 Hz
90 to 264 VAC;
48 to 62 Hz
90 to 264 VAC;
48 to 62 Hz
Power
consumption
printing
PAUSE test at
slowest speed
121 W 180 W 220 W 269 W
Printer idle 20 W 20 W 20 W 20 W
Environment Mode Temperature Relative Humidity
Operation Thermal Transfer 40° to 105°F
(5° to 40° C)
20 to 85% non-condensing
Direct Thermal 32° to 105°F
(0° to 40° C)
Storage Thermal Transfer or
Direct Thermal
–40° to 140°F
(–40° to 60° C)
5 to 85% non-condensing

Zebra 110Xi4 Specifications

General

Maximum resolution	203 x 203 DPI
Core diameter	76 mm
Ribbon length	300 m
Media thickness	0.076 - 0.305 mm
Maximum media length	3810 mm
Maximum roll diameter	203 mm
Supported paper width	102 mm
Media thickness (imperial)	0.003 - 0.012 \
Maximum media length (imperial)	150 \
Supported paper width (imperial)	4 \
RS-232 ports	1
Standard interfaces	USB 2.0
Connectivity technology	Wired
Weight (imperial)	50 lbs
Dimensions (WxDxH)	261.9 x 517.5 x 393.7 mm
Flash memory	8 MB
Certification	-BSMI, -cTUVus, -CCC, -CE, -C-Tick, -EN55022 Class B, -EN55024, -EN61000-3-2, 3, -FCC Class B, -GOST-R, -ICES-003 Class B, -IEC 60950-1 / EN60950, -KCC, -NOM, -S Mark, -STB, -UkrSEPRO, -VCCI, -ZIK.
Internal memory	16 MB
Built-in barcodes	Code 39, Code 49, Code 93, MaxiCode, PDF417, Postnet, QR Code, UPC-A, UPC-E
Page description languages	XML, ZPL, ZPL II
Storage temperature (T-T)	-40 - 140 °F
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Power requirements	90 - 264 VAC, 48 - 62 Hz

Weight and Dimensions

Weight	22700 g
