Zebra TC72 User Manual

Calls
20
To end a call using the wired headset, press and hold the headset button until the call ends.
Figure 29 3.5 mm Headset
Adjusting Audio Volume
• Use the volume buttons to adjust the phone volume.
• Ring and notification volumes when not in a call.
• Conversation volume during a call.
Making a Call Using the Dialer
Use the dialer tab to dial phone numbers.
1. On the Home screen touch .
2. Touch .
3. Touch the keys to enter the phone number.
4. Touch below the dialer to initiate the call.
• - Send audio to the speakerphone.
• - Mute the call.
• - Display the dial pad.
• - Place the call on hold (not available on all services).
• - Create a conference call.
• - Increase audio level.
5. Touch to end the call.
If using a Bluetooth headset, additional audio options are available. Touch the audio icon to open the audio
menu.
• - Audio is routed to the Bluetooth headset.
• - Audio is routed to the speakerphone.
• - Audio is routed to the earpiece.

Zebra TC72 Specifications

General

Display diagonal	4.7 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Internal memory	4 GB
Internal memory type	-
Total storage capacity	32 GB
Compatible memory cards	MicroSD (TransFlash), SDHC, SDXC
Processor model	660
Processor family	Snapdragon
Processor frequency	2.2 GHz
Processor manufacturer	Qualcomm
Operating system installed	Android
Rear camera aperture number	2.4
Rear camera resolution (numeric)	13 MP
Front camera resolution (numeric)	5 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery voltage	3.7 V
Battery capacity	4620 mAh
Scanner type	1D/2D
Product color	Black, Silver
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	28 mm
Width	84 mm
Height	161 mm
Weight	376 g
