PEDALS AND LEVERS CONTROLLED BY DRIVER
A 58a A 58b A 58c
∗ HI-LO - TORQUE MULTIPLIER
Tractors can be optionally equipped
with. torque multiplier. Torque multiplier
is electro-pneumatically controlled by
means of foot pedal located on the right
hand side of clutch pedal. The tractive
force of tractor is increased after
depression of Hi-Lo pedal. Number of
transmission gears is twice higher (20/4)
at tractors equipped with Hi-Lo.
Hi-Lo (torque multiplier) is automatically
disengaged after depressing of clutch
pedal, brake pedals or after applying of
PTO control lever (i.e. at disengaged
PTO shaft).
HI-LO FUNCTION INDICATION
The indicator light on dashboard lights
when the Hi-Lo is actuated.
SAFETY RULES WHEN WORKING
WITH HI-LO
For the reason of safety it is
forbidden to press the travel
clutch pedal and Hi-Lo pedal
simultaneously and to use the Hi-
Lo when going downhill.
