Zetor 3341 SUPER User Manual

93
FRONT DRIVING AXLE STOP SETTING AT Z 3341, Z 4341, Z 5341, Z 6341, Z 7341
A 126
SETTING OF STOPS
Set stops at each change of front wheel
tread according to the mentioned tables
after loosening of nut "2" and treading
out or in of screw "1" to value “A“.
tractor w/fenders
tire 9,5-24 11,2-24 11,2-24 12,4-24 13,6R24
treads A (mm) A (mm) A (mm) A (mm) A (mm)
1500
1583
1594
1650
1660
1734
1745
1800
1810
33
-
29
22
-
-
19
-
-
44
-
-
-
-
-
-
-
-
-
-
43
37
-
-
29
25
-
-
-
43
37
-
-
30
26
-
-
43
-
-
37
33
-
-
26
tractor w/o fenders
tire 9,5-24 11,2-24 11,2-24 12,4-24 13,6R24
treads A (mm) A (mm) A (mm) A (mm) A (mm)
1500
1583
1594
1650
1660
1734
1745
1800
1810
29
-
24
19
-
-
13
13
-
∗36
-
∗30
∗25
-
-
∗21
∗17
-
-
-
26
22
-
-
18
14
-
-
-
31
27
-
-
21
17
-
-
36
-
-
30
25
-
-
21
∗ - for Z 3341 only
