7 Error
7.1 Internal communication error
Communication of the two internal microcontrollers in the module is faulty.
Adjustment
Perform voltage reset at the complete device.
If the module still displays the error after the reset, adjustment is not possible!
The module is defective.
7.2 Member error message
If errors occur on a ZIEHL-ABEGG member, these are displayed directly on the affected device.
In this case please consult the appropriate operating instructions of the member.
8 Enclosure
8.1 Technical data
Voltage supply 24 V DC (
Imax
15 mA)
Interfaces
•
CAN-OPEN
– Terminal strip, 5-pole
– 5 V electrically isolated voltage, only suitable for termination
Optical display
•
1 x Run LED (green)
•
1 x Error LED (red)
•
1 x Adress LED (yellow)
Permissible ambient temperature -35...+80 °C
Permissible rel. humidity 85 % no condensation
Electromagnetic compatibility Interference emission EN 61000-6-3 (domestic household applications)
Interference immunity EN 61000-6-2 (industrial applications)
Housing protection IP20 (installed IP54)
Operating Instructions AM-CAN-OPEN – model series Error
L-BAL-E199-GB 1846 Index 005 Part.-No. 00163405-GB
20/28
