ZIEHL-ABEGG AM-CAN-OPEN User Manual

3 Product overview
3.1 Application
With this add-on module an ECblue, Icontrol Basic or Fcontrol Basic can be coupled to an existing
CAN-OPEN system.
3.2 Function
ECblue fans with integrated auxiliary module AM-CAN-OPEN offer the following functions:
•
With the “AM-CAN-OPEN” module communication is possible with the fan controller via a CAN-
OPEN network.
•
For programming of desired functions during start-up or for diagnostics.
•
The module can remain in the ECblue fan or be inserted only for the period of the programming.
3.3 Transport
•
The device is packed ex factory to suit the transport method previously agreed.
•
Always use the original packaging materials when transporting the device.
•
Avoid shocks and impacts to the device during the transport.
•
During manual handling the human lifting and carrying restrictions must be observed and adhered
to.
3.4 Storage
•
The device must be stored in its original packaging in a dry and weather-proof room.
•
Avoid exposure to extreme heat and cold.
•
Avoid over-long storage periods (we recommend a maximum of one year).
3.5 Disposal / recycling
Disposal must be carried out professionally and in an environmentally friendly way in accordance with
the respective national legal stipulations.
" Separate the materials by type and in an environmentally friendly way.
" If necessary, commission a specialist company with the waste disposal.
4 Mounting
•
Before installation remove the device from the packing and check for any possible shipping
damage!
•
For installation the cover of the controller housing must be removed. The module is then put into
the intended slot of the ECblue fan. (
Assembly instructions / Operating Instructions for fan /
Electrical Installation).
•
Then mount the module in the controller housing with the two enclosed screws (permissible
tightening torque M
A
= 1.3 Nm).
•
To mount in the frequency inverter, remove the complete housing lid and insert the module in the
slot provided (
Assembly Instructions / Operating Instructions of the Frequency Inverter /
Electrical Installation). There are two clips at the slot so that the add-on module does not have to be
screwed on.
•
Permissible tightening torque of connection terminals M
A
= 0.24 Nm.
Danger due to electric current
Voltage supply for motor must be interrupted and secured against restoration!
Operating Instructions AM-CAN-OPEN – model series Product overview
L-BAL-E199-GB 1846 Index 005 Part.-No. 00163405-GB
4/28
