8.3.4 Modulation
MB Holding Register 2, Address: h1 = Control
MB Holding Register 2, Address: h1 Modulation
Digital control is used for digital control of the device. The register bits controls digital functions.
The digital control has to be enabled for each bit
control mode register h4.
Access / necessary PIN protection level RW /
|
0
|
minimal value 0
maximum value 65535
Default 0
Bit [15] 1: K1 Control system
Bit [14] 1: Min. speed "OFF" (by ECblue only in combination with
Premium Modul, from FW10)
Bit [13:6] no function, reads 0
Bit [5] 1: Fire alarm (from Firmware 9.00)
Bit [4] 1: Reverse
Bit [3] 1: Limit (h18)
Bit [2] 1: Set Intern3 (h9) for control mode 0 + 4 (h4, Bit [3:0])
0 = input 0 - 10 V, 4 = Set Intern1
Bit [1] 1: Set Intern2 (h6) for control mode 0 + 4 (h4, Bit [2:0])
0 = input 0 - 10 V, 4 = Set Intern1
Bit [0] 1: Enable
MB Holding Register 3, Address: h2 = Speed control
MB Holding Register 3, Address: h2 Speed control
Used for speed control of the device. The interpretation of the value depends on control mode register (h4) Bit [3:0].
Access / necessary PIN protection level RW /
|
0
|
minimal value 0
maximum value 65535
Default 0
Bit [15:0] Decimal value 0 - 65535
Operating Instructions AM-CAN-OPEN – model series Enclosure
L-BAL-E199-GB 1846 Index 005 Part.-No. 00163405-GB
25/28
