5.3.2 LED-Display
There are three LEDs for the status display on the AM-CAN-OPEN:
•
Yellow LED: Address
•
LED red: Error
•
LED green: Run
A detailed description of the different LED combinations can be found in the chapter LED Functions.
Information
The LEDs are not visible when the lid of the ECblue or frequency inverter is closed.
5.3.3 CAN-OPEN
The AM-CAN-OPEN supports the following baudrates at the corresponding cable lengths
1 MBit/s / 20 m 125 kBit/s / 500 m
800 kBit/s / 40 m 50 kBit/s / 1000 m
500 kBit/s / 100 m 20 kBit/s / 2500 m
250 kBit/s / 250 m 10 kBit/s / 5000 m
The used baudrate is set by a rotary switch:
Switch position Baudrate Switch position Baudrate
0 1 MBit/ 5 100 kBit/s
1 800 kBit/s 6 50 kBit/s
2 500 kBit/s 7 20 kBit/s
3 250 kBit/s 8 do not use
4 125 kBit/s 9 do not use
Operating Instructions AM-CAN-OPEN – model series Electrical installation
L-BAL-E199-GB 1846 Index 005 Part.-No. 00163405-GB
7/28
