9Enclosure
9.1 Technical data
9.1.1 motor
Motor type ZAtop SM200.40E ZAtop SM200.45E
Suspension
1:1 2:1 1:1 2:1
Typical payload* [kg] 800 1600 800 1600
Rated torque [Nm] 600 710
Maximum torque [Nm] 1000 1200
maximum short circut torque [Nm] 480 at 25 rpm 480 at 25 rpm
permissible radial load [kg] 3300 3300
Speed [m/s] 1.6 1.6
Table 9-1-1
Table shows typical data, other values possible.
* Dependent on travel, compensation ropes may be necessary.
9.1.2 Traction sheaves
- Diameter
[mm] 160 200 240 240 320 400 500
- Width [mm] 143 106 124 173 122 95 90
Table 9-1-2
9.1.3 Protection rating
Component
Protection rating
motor
IP 21
Forced ventilation
IP 20
Absolute encoder
IP 40
Brake (electrical)
IP 54
Brake (mechanical)
IP 10
Complete machine
IP 21
Table 9-1-3
9.1.4 Ambient conditions
The user must ensure that the specified ambient conditions are observed.
Ambient temperature for operation [°C] 0 to +40
Humidity [%] Maximum 95 / condensation not permitted
Installation height [m above
sea]
Above 1000
Torque reduction by 1 % per 100 m or
On time reduction by 1.5 % per 100 m
Table 9-1-4
Translation of the original operating instructions
ZAtop – model series SM200.40E/SM200.45E Enclosure
A-TBA21_01-GB 2021/30 Index 003 Part.-No. 01013507-GB (EU-BD 1112)
29/64
