9.1.5 Brake
Brake type RTW 800
(information for each brake circuit)
Brake torque [Nm] 800
Operating voltage [V DC] 207
Power [W] 131
Electrical protection rating
IP 54
Mechanical protection rating
IP 10
Table 9-1-5
9.1.5.1 Micro switch
Minimum switching capacity
[mA / V DC] 10 / 12
Maximum rating [A / V AC] 3 / 250
Recommended rating [mA / V DC] 10 - 50 / 24
Table 9-1-5-1
9.1.5.2 Inductive proximity switch
Operating voltage
[V DC] 10 - 30
Rated operating current [mA DC] 100
Output functions
NC contact / gauge zero
Table 9-1-5-2
For further information refer to the “Appendix - Brake operating instructions - Assembly and adjust-
ment of the release monitor with inductive proximity switch” chapter.
Translation of the original operating instructions
ZAtop – model series SM200.40E/SM200.45E Enclosure
A-TBA21_01-GB 2021/30 Index 003 Part.-No. 01013507-GB (EU-BD 1112)
30/64
