5.4.3 Connecting IED with a test switch
When the IED is used with a test switch, connect the current and voltage
transformers directly to the switch.
5.5 Connecting binary signals
Each signal connector terminal is dimensioned for one 0.5...2.5 mm
2
wire or for
two 0.5...1.0 mm
2
wires.
Table 12: Binary inputs X304, 4U half 19” and 6U half 19”
Terminal Description
ACT info
Hardware module
instance
Hardware channel
X304-1 Common - for inputs 1-4
X304-2 Binary input 1 + COM_101 BI1
X304-3 Binary input 2 + COM_101 BI2
X304-4 Binary input 3 + COM_101 BI3
X304-5 Binary input 4 + COM_101 BI4
X304-6 Common - for inputs 5-8
X304-7 Binary input 5 + COM_101 BI5
X304-8 Binary input 6 + COM_101 BI6
X304-9 Binary input 7 + COM_101 BI7
X304-10 Binary input 8 + COM_101 BI8
X304-11 Common - for inputs 9-11
X304-12 Binary input 9 + COM_101 BI9
X304-13 Binary input 10 + COM_101 BI10
X304-14 Binary input 11 + COM_101 BI11
X304-15 Common - for inputs 12-14
X304-16 Binary input 12 + COM_101 BI12
X304-17 Binary input 13 + COM_101 BI13
X304-18 Binary input 14 + COM_101 BI14
Table 13: Binary inputs X319, 4U half 19”
Terminal
Description ACT info
Hardware module
instance
Hardware channel
X319-1 - for input 1 BIO_3 BI1
X319-2 Binary input 1 + BIO_3 BI1
X319-3 -
X319-4 Common - for inputs 2-3
Table continues on next page
1MRS755958 C Section 5
Connecting
630 series 47
Installation Manual
