ABB 630 series Installation Manual

9.2 Connector sets
Table 46: Connector sets for REF630 and REM630
Item Order number
Connector set for one 4U half 19" housing IED including analog input
variant 4I + 5U (Io 1/5A), 5I + 4U (Io 0.1/0.5A) or 4I + 5U (Io 0.1/0.5A)
2RCA021735
Connector set for one 6U half 19" housing IED including analog input
variant 4I + 5U (Io 1/5A), 5I + 4U (Io 0.1/0.5A) or 4I + 5U (Io 0.1/0.5A)
2RCA021736
Table 47: Connector sets for RET630
Item Order number
Connector set for one 4U half 19" housing IED including analog input
variant 7I (I0 1/5A) + 3U
2RCA023041
Connector set for one 6U half 19" housing IED including analog input
variant 7I (I0 1/5A) + 3U
2RCA023042
Connector set for one 4U half 19" housing IED including analog input
variant 8I (I0 1/5A) + 2U or 7I (I0 1/5A) + 1I (I0 0.1/0.5A) + 2U
2RCA023039
Connector set for one 6U half 19" housing IED including analog input
variant 8I (I0 1/5A) + 2U or 7I (I0 1/5A) + 1I (I0 0.1/0.5A) + 2U
2RCA023040
9.3 Cables
Table 48: Optional cables for external display module
Items
Order number
LHMI cable (1m) 2RCA025073P0001
LHMI cable (2m) 2RCA025073P0002
LHMI cable (3m) 2RCA025073P0003
LHMI cable (4m) 2RCA025073P0004
LHMI cable (5m) 2RCA025073P0005
1MRS755958 C Section 9
Accessories and ordering data
630 series 81
Installation Manual
