GUID-3A4996EE-1443-433C-B11B-A804592A9511 V1 EN
Figure 41: 4U wall mounting brackets
Table 43: Mounting kit
Items
Order number
Wall-mounting kit (cabling towards the mounting wall) for one 4U half 19”
housing IED
1KHL400067R0001
9.1.7 Ceiling mounting kit for a main unit
• Mounting bracket
• Screws
• Dimensions for screw holes
Section 9 1MRS755958 C
Accessories and ordering data
76 630 series
Installation Manual
