ABB Ability 800xA Series User Manual

B.5 Data Format for Schedule Domain
The format for the data of a schedule domain is described in IEC 61158-4:2014 Data
Link Layer Protocol Specification. A schedule domain consists of the schedule summary
and n sub-schedules. A sub-schedule contains m sequences and one sequence has x
sequence elements.
B.5.1 Schedule Summary
OctetsRange of valuesMeaning
10xffschedule identifier
10 - 7transfer version number
21 - 0xffffschedule version
20x100 - 0xfffbuilder identifier
11 - 4number sub-schedules
1unusedV(MSO)
2storage for schedule
2unusedresolution
2unusedV(MRD)*V(ST)
2unusedThisLink of Originator
6unusedperiodic time base
41 - 0xffffffffmacrocycle duration
21 - 0xffffsub-schedule reference 1
21 - 0xffffsub-schedule reference i
21 - 0xffffsub-schedule reference n
2 * l, I = 1, 2, 3, ...0end of summary
B.5.2 Sub-Schedule
OctetsRange of valuesMeaning
10xffschedule identifier
10x08 + (0 - 7)transfer version number
2PAA114135-610 103
B Technical Reference
B.5 Data Format for Schedule Domain
