4 Built-in Web Server
General information about the Linking Device can be queried via the web pages of the
built-in web server, refer to Logging in to the Web Server Interface on page 59. This
requires a standard web browser supporting JavaScript (e. g. Microsoft Internet Explorer)
on a PC that is connected to the Linking Device via Ethernet, refer to Setting Up an IP
Connection Between PC and Linking Device on page 54, for configuring an Ethernet
connection between a PC and the Linking Device.
LD 810HSE Ex web server Disable functionality is performed only after LD initialization
and download of first configuration parameters. The LD 810HSE Ex web server can
only be accessed if it is enabled in Fieldbus Builder FOUNDATION™ Fieldbus and
is automatically disabled after one hour.
The contents of the web server pages depend on the logged in user type
(Operat/Config/Diag).
To address the Linking Device in the browser, use its IP address as URL, e. g.
HTTPS://192.168.0.10.
In Microsoft Internet Explorer, press the CTRL and F5 keys to show subsequent
updates of LD 810HSE Ex web page content.
The sub menus under Information category display current values read from the device.
They are not protected by a password. As these pages are dynamically generated, it
may take a short time to display them. The contents of these pages that contain mainly
diagnostic information are explained in the following subsections.
• System Status
• System Diagnostics
• H1 Diagnostics
• Hardware Diagnostics
• Version Information
2PAA114135-610 75
