6 E-Clipse Bypass Configurations for ACH550 Drives
Installation
The following shows the front view of the ACH550 E-Clipse Bypass vertical
configuration, and identifies the major components.
The following shows the front view of the ACH550 E-Clipse Bypass standard
configurations, and identifies the major components.
BP0091
E-Clipse Bypass
E-Clipse Bypass Control Panel
Operating Handle
for Disconnect Switch
or Circuit Breaker
ACH-CP-B
Control Panel
ACH550 Drive
BP0092
ACH-CP-B
E-Clipse Bypass
Operating Handle
ACH550 Drive with E-Clipse Bypass
Control Panel
for Disconnect Switch
or Circuit Breaker
E-Clipse Bypass
(R8)
Control Panel

ABB ACH550 series Specifications

General

Enclosure	IP21, IP55
Output Voltage	0 to Supply Voltage
Frequency Range	0 to 500 Hz
Control Method	Scalar control, vector control
Braking Chopper	Optional
Communication	Modbus RTU, Profibus, CANopen, Ethernet
Storage Temperature	-40°C to +70°C
Relative Humidity	5 to 95 % RH, non-condensing
Altitude	Up to 1000 m (derating above 1000 m)
Cooling Method	Air-cooled
