ACH550 Installation, Operation and Maintenance Manual 27
ACH550-UH
35 OUTPUT WIRING Possible power wiring error detected. When the drive is not running it
monitors for an improper connection between the drive input power and the
drive output. Check for and correct:
• Proper input wiring – line voltageis NOT connected to drive output.
• The fault can be erroneously declared if the input power is a delta
grounded system and motor cable capacitance is large. This fault can be
disabled using parameter 3023
WIRING FAULT.
36
INCOMP
SWTYPE
The drive cannot use the software.
• Internal Fault.
• The loaded software is not compatible with the drive.
• Call support representative.
37
CB OVERTEMP Drive control board is overheated.
Check for and correct:
• Excessive ambient temperatures
• Fan failure.
• Obstructions in the air flow.
38
USER LOAD
CURVE
Condition defined by parameter 3701 USER LOAD C MODE has been valid
longer than the time defined by 3703 USER LOAD C TIME.
101
SERF CORRUPT Error internal to the drive. Contact your local ABB sales representative and
report the error number.
102
RESERVED
103 SERF MACRO
104
RESERVED
105 RESERVED
201 DSP T1
OVERLOAD
Error in the system. Contact your local ABB sales representative and report
the error number.
202
DSP T2
OVERLOAD
203
DSP T3
OVERLOAD
204
DSP STACK
ERROR
205
RESERVED
(obsolete)
206
OMIO ID ERROR
207
EFB LOAD ERR
1000 PAR HZRPM
LIMITS
Parameter values are inconsistent. Check for any of the following:
• 2001
MINIMUM SPEED > 2002 MAXIMUM SPEED.
• 2007
MINIMUM FREQ > 2008 MAXIMUM FREQ.
• 2001
MINIMUM SPEED / 9908 MOTOR NOM SPEED is outside proper range
(> 50)
• 2002
MAXIMUM SPEED / 9908 MOTOR NOM SPEED is outside proper range
(> 50)
• 2007
MINIMUM FREQ / 9907 MOTOR NOM FREQ is outside proper range
(> 50)
• 2008 MAXIMUM FREQ / 9907 MOTOR NOM FREQ is outside proper range
(> 50)
1001 PAR PFAREFNG Parameter values are inconsistent. Check for the following:
• 2007
MINIMUM FREQ is negative, when 8123 PFA ENABLE is active.
Fault
Code
Fault Name In
Panel
Description and Recommended Corrective Action

ABB ACH550-UH HVAC Specifications

General

Frequency	50/60 Hz
Output Frequency	0 to 500 Hz
Voltage Range	200-240V, 380-480V, 500-600V
Power Range	1 to 550 HP
Control Method	Vector control
Protection Class	IP21
Communication Protocols	Modbus, BACnet, N2
Cooling Method	Air cooled
Enclosure Type	Wall-mounted
