Parameters 139
I/s I/s 13
I/min I/min 14
I/h I/h 15
m
3
/s m
3
/s 16
m
3
/m m
3
/m 17
km
3
/h km
3
/h 18
gal/s gal/s 19
ft
3
/s ft
3
/s 20
ft
3
/m ft
3
/m 21
ft
3
/h ft
3
/h 22
ppm ppm 23
inHg inHg 24
kCFM kCFM 25
inWC inWC 26
GPM GPM 27
gal/m gal/m 28
in wg in wg 29
MPa MPa 30
ftWC ftWC 31
40.89 Set 1 setpoint
multiplier
Defines the multiplier with the result of parameter 40.16 Set 1
setpoint 1 source.
1.00
-200000.00…
200000.00
Multiplier. -
40.90 Set 1 feedback
multiplier
Defines the multiplier with the result of parameter 40.08 Set 1
feedback 1 source.
1.00
-200000.00…
200000.00
Multiplier. 1 = 1
40.91 Feedback data
storage
Storage parameter for receiving a process feedback value eg.
through the embedded fieldbus interface.
The value can be sent to the drive as Modbus I/O data. Set
the target selection parameter of that particular data
(58.101…58.114) to Feedback data storage. In 40.08 Set 1
feedback 1 source, select Feedback data storage.
0.00
-327.68…327.67 Storage parameter for process feedback. 100 = 1
40.92 Setpoint data
storage
Storage parameter for receiving a process setpoint value eg.
through the embedded fieldbus interface.
The value can be sent to the drive as Modbus I/O data. Set
the target selection parameter of that particular data
(58.101…58.114)) to Setpoint data storage. In 40.16 Set 1
setpoint 1 source, select Setpoint data storage.
0.00
-327.68…327.67 Storage parameter for process setpoint. 100 = 1
40.96 Process PID
output%
Percentage scaled signal of parameter 40.01 Process PID
feedback actual. Correct later.
0.00
-100.00...100.00% Percentage. 1=1
No. Name/Value Description Def/FbEq16
ACQ80 FW.book Page 139 Thursday, February 14, 2019 11:33 AM
