70 Parameters
01.61 Abs motor speed
used
Shows absolute value of parameter 01.01 Motor speed used.-
0.00… 30000.00
rpm
Absolute motor speed in rpm. 1 = 1 rpm
01.62 Abs motor speed % Shows absolute value of parameter 01.03 Motor speed %.-
0.00… 1000.00% Absolute motor speed in %. 10 = 1%
01.63 Abs output
frequency
Shows absolute value of parameter 01.06 Output frequency.-
0.00…500.00 Hz Absolute output frequency. 10 = 1 Hz
01.64 Abs motor torque Shows absolute value of parameter 01.10 Motor torque.-
0.0…1600.0% Motor torque. 10 = 1%
01.65 Abs output power Shows absolute value of parameter 01.14 Output power.-
0.00… 32767.00
kW
Output power. 1 = 1 kW
01.66 Abs output
power % motor
nom
Shows absolute value of parameter 01.15 Output power % of
motor nom.
-
0.00… 300.00% Output power. 1 = 1%
01.67 Abs output
power % drive nom
Shows absolute value of parameter 01.16 Output power % of
drive nom.
-
0.00… 300.00% Output power. 1 = 1%
01.68 Abs motor shaft
power
Shows absolute value of parameter 01.17 Motor shaft power.-
0.00… 32767.00
kW or hp
Motor shaft power. 1 = 1 kW
01.69 Load Speed Not applicable.
03
03 Input references
Values of references received from various sources.
All parameters in this group are read-only unless otherwise
noted.
03.01 Panel reference Shows reference 1 given from the control panel or PC tool. -
-100000.00…
100000.0
0
Control panel or PC tool reference. 1 = 1
0
03.02 Panel reference
remote
Shows reference 2 given from the control panel or PC tool. -
-100000.00…
100000.0
0
Control panel or PC tool reference. 1 = 1
0
03.05 FB A reference 1 Shows reference 1 received through fieldbus adapter A.
See also chapter Fieldbus control through a fieldbus adapter
(page 249).
-
-100000.00…
100000.00
Reference 1 from fieldbus adapter A. 1 = 10
03.06 FB A reference 2 Shows reference 2 received through fieldbus adapter A. -
-100000.00…
100000.00
Reference 2 from fieldbus adapter A. 1 = 10
No. Name/Value Description Def/FbEq16
ACQ80 FW.book Page 70 Thursday, February 14, 2019 11:33 AM
