ABB ACQ80-04 User Manual

Parameters 77
06.19 Speed control
status word
Speed control status word.
This parameter is read-only.
0b0000
0b0000...0b1111 Spee d control status word. 1 = 1
06.29 MSW bit 10
selection
Selects a binary source whose status is transmitted as bit 10
(User bit 0) of 06.11 Main status word.
Above limit
False 0 0
True 1 1
Above limit Bit 10 of 06.17 Drive status word 2 (see page 76). 2
06.30 MSW bit 11
selection
Selects a binary source whose status is transmitted as bit 11
(User bit 0) of 06.11 Main status word.
Ext ctrl loc
False 0 0
True 1 1
Ext ctrl loc Bit 11 of 06.01 Main control word (see page 75). 2
Other [bit] Source selection (see Terms and abbreviations on page 64). -
06.31 MSW bit 12
selection
Selects a binary source whose status is transmitted as bit 12
(User bit 1) of 06.11 Main status word.
Ext run
enable
False 0. 0
True 1. 1
Ext run enable Status of the external run enable signal. 2
Other [bit] Source selection (see Terms and abbreviations on page 64). -
06.32 MSW bit 13
selection
Selects a binary source whose status is transmitted as bit 13
(User bit 2) of 06.11 Main status word.
False
False 0. 0
True 1. 1
Other [bit] Source selection (see Terms and abbreviations on page 64). -
06.33 MSW bit 14
selection
Selects a binary source whose status is transmitted as bit 14
(User bit 3) of 06.11 Main status word.
False
False 0. 0
True 1. 1
Other [bit] Source selection (see Terms and abbreviations on page 64). -
07
07 System info
Drive hardware and firmware information.
All parameters in this group are read-only.
07.03 Drive rating id Type of the drive. (Rating ID in brackets.) Not selected
07.04 Firmware name Firmware identification. -
07.05 Firmware version Version number of the firmware. 0.00.0.0
No. Name/Value Description Def/FbEq16
Bit Name Description
0 Zero speed Drive has been running below zero speed limit (30.00 rpm).
1 Forward 1 = Drive is running in forward direction above zero speed limit.
2 Reverse 1 = Drive is running in reverse direction above zero speed limit.
3…6 Reserved
7
Any constant speed
request
Not applicable.
8…15 Reserved
ACQ80 FW.book Page 77 Thursday, February 14, 2019 11:33 AM
