ABB ACQ80-04 User Manual

120 Parameters
32.56 Supervision 6
action
Selects whether the drive generates a fault, warning or
neither when the value monitored by signal supervision 6
exceeds its limits.
Note: This parameter does not affect the status indicated by
32.01 Supervision status.
No action
No action No warning or fault generated. 0
Warning Warning A8B5 Signal supervision 6 is generated. 1
Fault Drive trips on fault 80B5 Signal supervision 6.2
Fault if running Drive trips on fault 80B0 Signal supervision 1 if the motor is
running.
3
32.57 Supervision 6
signal
Selects the signal to be monitored by signal supervision
function 6.
For the available selections, see parameter 32.07
Supervision 1 signal.
Zero
32.58 Supervision 6 filter
time
Defines a filter time constant for the signal monitored by
signal supervision 6.
0.000 s
0.000 … 30.000 s Signal filter time. 1000 = 1 s
32.59 Supervision 6 low Defines the lower limit for signal supervision 6. 0.00
-21474836.00…
21474836.00
Low limit. -
32.60 Supervision 6 high Defines the upper limit for signal supervision 6. 0.00
-21474836.00…
21474836.00
Upper limit. -
32.61 Supervision 6
hysteresis
Defines the hysteresis for the signal monitored by signal
supervision 6.
0.00
0.00…100000.00 Hysteresis. -
35
35 Motor thermal
protection
Motor thermal protection settings such as temperature
measurement configuration, load curve definition and motor
fan control configuration.
See also section Motor thermal protection (page 44).
35.01 Motor estimated
temperature
Shows motor temperature as estimated by the internal motor
thermal protection model (see parameters 35.50…35.55).
The unit is selected by parameter 96.16 Unit selection.
This parameter is read-only.
0
-60…1000 °C or
-76…1832 °F
Estimated motor temperature. 1 = 1°C
35.02 Measured
temperature 1
Shows temperature received through the source defined by
parameter 35.11 Temperature 1 source. The unit is selected
by parameter 96.16 Unit selection.
Note: With a PTC sensor, the value shown is not a valid
measurement. Either 0 ohm (normal temperature) or the
value of parameter 35.22 Temperature 2 fault limit (excessive
temperature) is shown.
This parameter is read-only.
0
-60…5000 °C or
-76…9032 °F
Measured temperature 1. 1 = 1 unit
No. Name/Value Description Def/FbEq16
ACQ80 FW.book Page 120 Thursday, February 14, 2019 11:33 AM
