Technical data 115

Technical data

Contents of this chapter

This chapter contains the technical specifications of the drive, for example, the ratings,

sizes and technical requirements, provisions for fulfilling the requirements for CE and other

markings.

Ratings

The ratings of the drive modules with 50&60 Hz supply are given below.

 IEC ratings

See definitions and notes on page 116.

IEC RATINGS

Drive type

ACS530-04-

Frame

size

Input

current

Output ratings

Nominal use Light-duty use

max

AAAkWAkW

= 380…415 V (380, 400, 415 V)

505A-4 R10 505 560 505 250 485 250

585A-4 R10 585 730 585 315 575 315

650A-4 R10 650 730 650 355 634 355

725A-4 R11 725 1020 725 400 715 400

820A-4 R11 820 1020 820 450 810 450

880A-4 R11 880 1100 880 500 865 500

3AXD00000586715
