ABB ACS530-04 User Manual

Introduction to the manual 25
Terms and abbreviations
Term/Abbreviation Explanation
ACS-AP-x Assistant control panel, advanced operator keypad for communication with the
drive. The ACS530 supports types ACS-AP-I, ACS-AP-S and ACS-AP-W.
ACS-BP-S Basic control panel
CCA-01 Optional communication adapter
CHDI-01 Optional 115/230 V digital input extension module
CMOD-01 Optional multifunction extension module (external 24 V AC/DC and digital I/O
extension)
CMOD-02 Optional multifunction extension module (external 24 V AC/DC and isolated PTC
interface)
CMF Common mode filtering
EMC Electromagnetic compatibility
EMI Electromagnetic interference
FCAN-01 Optional CANopen adapter module
FCNA-01 Optional ControlNet fieldbus adapter module
FDNA-01 Optional DeviceNet™ fieldbus adapter module
FECA-01 Optional EtherCAT adapter module
FENA-11 Optional high performance Ethernet/IP™, Modbus/TCP and PROFINET IO
adapter module
FENA-21 Optional 2-port Ethernet (EtherNet/IP, Modbus/TCP, PROFINET) adapter module
FEPL-02 Optional Ethernet POWERLINK
fieldbus adapter module
FPBA-01 Optional PROFIBUS DP adapter module
Frame (size) Size of the drive module. The drive modules described in this manual are of frame
size R10 and R11.
FSCA-01 Optional Modbus RTU adapter module
IGBT Insulated gate bipolar transistor; a voltage-controlled semiconductor type widely
used in converters due to their easy controllability and high switching frequency.
I/O Input/Output
IT system Type of supply network that has no (low-impedance) connection to ground.
NETA-21 Remote monitoring tool
PLC Programmable logic controller
RFI Radio-frequency interference
STO Safe torque off
TN system Type of supply network that provides a direct connection to ground.
