Operation principle and hardware description 35
Option codes (plus codes)
Control panel and mounting platform
J400 Assistant control panel ACS-BP-S
0J400 No control panel. Note: You need at least one loose control panel to be able to commission the
drive.
J404 Basic control panel ACS-BP-S
J410 DPMP-03 Cabinet door mounting kit
J425 Assistant control panel compatible with ACS530 drives (ACS-AP-I)
J429 Assistant control panel with bluetooth interface ACH-AP-W
Fieldbus adapter modules
K451 FDNA-01 DeviceNet™ fieldbus adapter module
K454 FPBA-01 PROFIBUS DP fieldbus adapter module
K457 FCAN-01 CANopen fieldbus adapter module
K458 FSCA-01 Modbus/RTU adapter module
K462 FCNA-01 ControlNet fieldbus adapter module
K469 FECA-01 EtherCAT
®
fieldbus adapter module
K470 FEPL-02 Ethernet POWERLINK
fieldbus adapter module
K490 FEIP-21
K491 FMBT-21
K492 FPNO-21
I/O extension and feedback interface modules
L501 CMOD-01 external 24 V DC/AC and digital I/O extension module (two relay outputs and one digital
output)
L512 CHDI-01 115/230 V digital input module (six digital inputs and two relay outputs)
L523 CMOD-02 external 24 V and isolated PTC interface
L537 CPTC-02 ATEX Certified PTC interface and external 24V. Requires also option +Q971.
Specialities
P931 Extended warranty 36 extends the total warranty to 36 months from delivery.
P932 Extended warranty 60 extends the total warranty to 60 months from delivery.
Safety
Q971 CPTC-02 ATEX-certified Safe Disconnection Function, EX II (2) GD. Option Q971 sold only
together with option L537.
Paper manuals. Note: The delivered manual set can include manuals in English if the translation is not
available.
R700 English
R701 German
R702 Italian
R707 French
R708 Spanish
R712 Chinese
Code Description

ABB ACS530-04 Specifications

General

Brand	ABB
Model	ACS530-04
Category	Controller
Language	English
