8.6 Standard toolkit
General
All service (repairs, maintenance, and installation) procedures contains lists of
tools required to perform the specified activity.
All special tools required are listed directly in the procedures while all the tools
that are considered standard are gathered in the standard toolkit and defined in
the following table.
This way, the tools required are the sum of the standard toolkit and any tools listed
in the instruction.
Contents, standard toolkit
CommentToolQty
Ring-open-end spanner 8-19 mm1
Socket head cap 2.5-17 mm1
Torx socket no: 20-601
Box spanner set1
Torque wrench 10-100 Nm1
Torque wrench 75-400 Nm1
Ratchet head for torque wrench 1/21
Hexagon-headed screw M10x1002
Hexagon-headed screw M16x901
Hex bit socket head cap no. 14 socket 40 mm L=100 mm1
To be shortened to 12 mmHex bit socket head cap no. 14 socket 40 mm L=20 mm1
Hex bit socket head cap no. 6 socket 40 mm L=145 mm1
Hex bit socket head cap no. 6 socket 40mm bit L=220 mm1
Plastic mallet1
Product manual - IRB 6700 829
3HAC044266-001 Revision: N
