101510 Rev. AG Page 3–
3.4.1 Material required
• One 2 inch pipe with flange
• One 2 inch pipe coupling
or
• One 2 inch mounting pipe (installed). Length dependent upon final overall
NGC desired height.
Optional equipment may be ordered from Totalflow.
3.4.2 Instructions
1) Select a location to install the mounting pipe that allows easy access and is
close to the sample probe. Lines should be as short as possible.
2) Install a mounting pipe, and ensure the pipe is vertically aligned.
3) Screw 2 inch pipe coupling onto the top of the mounting pipe.
4) Screw optional mounting flange pipe into the top of the pipe coupling.
Continue to the NGC Installation instructions.
Method of installation must be consistent with customer’s
company policy.
3.5 Large Free-standing Environmental Enclosure Installation
If the installation includes a free-standing environmental
enclosure, follow these instructions; otherwise, skip to the
next section.
The following steps will typically require two people.
3.5.1 Materials
• 4 ea. ½-13 x 1 ¼ SST bolt
• 4 ea. ½ SST flat washer
• 4 ea. ½” SST split washer
• 1 ea. stand
3.5.2 Installation
1) The stand is symmetrical, so the top and bottom are identical. Locate the
stand base on a flat, stable, surface.
2) Set the enclosure on top of the stand, oriented so that the stand brace is
horizontal with the front of the enclosure (see Figure 3-5
).
