ABB PST Series User Manual

25
1SFC132003M0201
'HVFULSWLRQ
&KDSWHU
 7HFKQLFDOGDWD
 *HQHUDO
*HQHUDOGDWD
Rated insulation voltage, U
i
690 V
Rated operational voltage, U
e
208 - 690 V
Rated supply voltage, U
s
100 - 250 V 50/60 Hz
Rated frequency 50 / 60 Hz
Voltage tolerances +10% to -15%
Frequency tolerances + 5%
Rated impulse withstand voltage 2 kV
Number of controlled phases 3
Programmable inputs 24 V DC, 10mA
Output relays 250 V AC, Ith = 5A, Ie = 1.5A (AC-15)
Cooling system Fan
Recommended fuse
supply circuit
6A Delayed
Service factor 115% (100% for PSTB1050)
Communication protocols AS-I / DeviceNet
