ABB PST Series User Manual

73
1SFC132003M0201
6HWWLQJVDQGFRQILJXUDWLRQ
&KDSWHU
 )XQFWLRQDO6HWWLQJV
The Functional setting menu consists of groups with
parameters arranged by function such as protection,
warning, fault, fieldbus communication etc. This menu
should be used if a more advanced set-up is required. For
a detailed description of each parameter, see Chapter 10
“Functions” .
(QWHUWKH)XQFWLRQDOVHWWLQJV
Enter the menu by selecting )XQFWLRQDO6HWWLQJV.
 6WDUW6WRS
To set parameters related to start and stop, enter the 6WDUW
6WRS group. Following parameters are available in this
group:
• Setting I
e
•External By-Pass
• Start ramp
• Stop ramp
• Initial voltage
• End voltage
• Step down voltage
• Current limit level
•Kick start
• Kick level
• Kick time
• Start range
• Stop range
Setting of parameters from Setting I
e
to Current limit level
above, see “Basic Settings” .
T
op level
Settings
)LJXUH )XQFWLRQDO6HWWLQJVPHQX
Application
Settings
Basic
Settings
Functional
Settings
Service
Settings
Presentation
Settings
All
Settings
Changed
Settings
Reset all
Settings
Functional Settings
Start/Stop
Protections
Warnings
Inputs
Faults
Outputs
Fieldbus
)LJXUH 6WDUW6WRSJURXS
Settings
Seq Start
