27
1SFC132003M0201
'HVFULSWLRQ
&KDSWHU
:HLJKWV
7\SH 367 367% 367% 367%
Connection type Line Delta Line Delta Line Delta Line Delta
Rated current I
e
(A) 300 515 370 640 470 814 570 987
Motor size 380 - 415V (kW) 160 257 200 35 250 450 315 475
Motor size 500V (kW) 200 355 250 450 315 600 400 625
Motor size 690V (kW) 257 500 355 600 450 800 560 860
DOL rating built in by-pass 400V (A) - 260 400 400
Power loss at rated current (W) 920 90 110 105
Power supply requirements (VA) / pull in 15 20/480 20/480 25/900
7\SH 367% 367% 367%
Connection type Line Delta Line Delta Line Delta
Rated current I
e
(A) 2720 1247 840 1455 1050 1810
Motor size 380 - 415V (kW) 400 670 450 780 560 875
Motor size 500V (kW) 500 880 560 1000 730 1150
Motor size 690V (kW) 710 1200 800 1400 965 1590
DOL rating built in by-pass 400V (A) 580 750 750
Power loss at rated current (W) 110 170 170
Power supply requirements (VA) / pull in 25/860 25/860 25/860
7\SH :HLJKWLQNJ :HLJKWLQOEV
PST30...50 4,8 10,6
PST60...72 5,0 11,0
PST85 11,2 24,7
PST105...142 13,0 28,7
PST175...210 21,5 47,4
PST250...300 23,0 50,7
PST370...470 31,0 68,3
PSTB570 52,0 114,6
PSTB720 55,0 121,3
PSTB840...1050 60,0 132,3
