ABB PST Series User Manual

86 1SFC132003M0201
6HWWLQJVDQGFRQILJXUDWLRQ
&KDSWHU
 2XWSXWV
To set parameters related to the programmable outputs,
enter the Outputs group.
5HOD\.
Select the required function for the output relay K4.
One of the following functions can be selected:
Run Run indication.
TOR Top of ramp indication.
Event Indication of selected event(s) where
following functions can be selected
individually:
• Motor overload protection
•Fault
• High current protection
• SCR overload protection
• Locked rotor protection
• Underload protection
• Phase imbalance protection
• PTC protection
• Phase reversal protection
• Overload warning
• SCR overload warning
• High current warning
• Low current warning
Press 6WRUH to save/activate the selected function.
5HOD\.
Select the required function for the output relay K5.
One of the following functions can be selected:
Run Run indication.
TOR Top of ramp indication.
Event Indication of selected event(s), see relay K4.
Press 6WRUH to save/activate the selected function.
Functional Settings
Start/Stop
Protections
Warnings
Inputs
Faults
Outputs
Fieldbus
)LJXUH 2XWSXWVJURXS
Settings
Seq Start
