2.3.1.21 LD0.EFHPTOC1 Non-directional earth-fault protection, high stage (1)
Table 24: LD0.EFHPTOC1 Non-directional earth-fault protection, high stage (1)
BitA
RegA IEC 61850 name SA name Description Values
LD0.EFHPTOC1
2944 184.00 .Str.general START Stage start 1=Start
2945 184.01 .mcd
2946 184.02 .Op.general OPERATE Stage operate 1=Operate
2947 184.03 .mcd
2.3.1.22 LD0.EFHPTOC2 Non-directional earth-fault protection, high stage (2)
Table 25: LD0.EFHPTOC2 Non-directional earth-fault protection, high stage (2)
BitA RegA IEC 61850 name SA name Description Values
LD0.EFHPTOC2
2952 184.08 .Str.general START Stage start 1=Start
2953 184.09 .mcd
2954 184.10 .Op.general OPERATE Stage operate 1=Operate
2955 184.11 .mcd
2.3.1.23 LD0.EFLPTOC1 Non-directional earth-fault protection, low stage (1)
Table 26: LD0.EFLPTOC1 Non-directional earth-fault protection, low stage (1)
BitA
RegA IEC 61850 name SA name Description Values
LD0.EFLPTOC1
2940 183.12 .Str.general START Stage start 1=Start
2941 183.13 .mcd
2942 183.14 .Op.general OPERATE Stage operate 1=Operate
2943 183.15 .mcd
2.3.1.24 LD0.EFLPTOC2 Non-directional earth-fault protection, low stage (2)
Table 27: LD0.EFLPTOC2 Non-directional earth-fault protection, low stage (2)
BitA
RegA IEC 61850 name SA name Description Values
LD0.EFLPTOC2
2948 184.04 .Str.general START Stage start 1=Start
2949 184.05 .mcd
2950 184.06 .Op.general OPERATE Stage operate 1=Operate
2951 184.07 .mcd
Section 2 1MRS756878 H
Modbus data mappings
24 RET615
Point List Manual
