RegA Type Scale IEC 61850 name SA name Description Values
2066 u16 1 .WacTrg.stVal Num. of watchdog resets 0...65535
2067 u16 1 .NumCmpChg.stVal Num. of conf. changes 0...65535
LD0.LLN0
u16 1 .ParChgCnt.stVal Num. of setting changes 0…65535
1) See the technical manual.
2.4.1.24 Time and reason for latest protection relay reset
Table 127: Time and reason for latest protection relay reset
RegA Type Scale IEC 61850 name SA name Description Values
9221 u16 1 Year 2000...2999
9222 u16 1 Month 1...12
9223 u16 1 Day 1...31
9224 u16 1 Hour 0...23
9225 u16 1 Minute 0...59
9226 u16 1 Second 0...59
9227 u16 1 Millisecond 0…999
9228 u16 1 Reset reason
9228.0 Bit - bit 0 1=Cold start
9228.1 Bit - bit 1 1=Watchdog
9228.2 Bit - bit 2 1=Warm start
2.4.1.25 User-definable bits [Alt.2], visible on 0x,1x,3x and 4x
Table 128: User-definable bits [Alt.2], visible on 0x,1x,3x and 4x
BitA
Type Scale IEC 61850 name SA name Description Values
(0) Bit < not mappable - not visible >
1 Bit Usr reg 1.Bit 01
2 Bit Usr reg 1.Bit 02
3 Bit Usr reg 1.Bit 03
: : :
: : :
15 Bit Usr reg 1.Bit 15
16 Bit Usr reg 2.Bit 00
17 Bit Usr reg 2.Bit 01
: : :
: : :
2046 Bit Usr reg 127.Bit 14
2047 Bit Usr reg 127.Bit 15
Section 2 1MRS756878 H
Modbus data mappings
70 RET615
Point List Manual
